从已保存的工作簿历史记录中导出 Excel 任务完成日期

如果你的 XLSX 文件保留了分配的任务的历史记录,就可以提取其中有效的完成事件及其 UTC 时间。这个本地导出程序也会在文件无法提供这些信息时明确指出。

三张卡片区分了批注的添加时间、批注线程是否已解决的状态,以及带有 UTC 时间的文档任务事件。保存的历史记录中,一次有效的 Progress 从低于 100 变为 100 的状态转换,才能提供完成事件时间;缺少任务历史记录时,该信息不可用。
原创说明示意图。CommentThreaded.Date 记录添加批注的时间,done 标记记录批注线程是否已解决。要从已保存的数据中取得任务完成时间,任务历史记录中必须存在一次有效的 Progress 从低于 100 变为 100 的状态转换。 Watch at Ease

Excel 批注导出结果可能遗漏标为 Completed Task 的条目。批注的创建时间、最后一条回复的时间,以及任务达到完成状态的时间,回答的是不同的问题。用其中一种时间替代另一种,会让报表中出现看似合理却错误的日期。

已保存的 XLSX 文件可能包含单独的文档任务历史记录。下方程序会检查这些已保存的数据,将任务与线程式批注的 ID 关联,并导出它能验证的事件。如果缺少必要的历史记录,结果会明确说明。它不会根据批注的 done 标记编造批注线程的解决时间,也不保证每个 Excel 版本或导出工具都会保留任务历史记录。

1. 先确认你需要哪一种日期

如果批注或回复的导出结果缺少分配的任务的完成信息,而你想检查已保存的工作簿,就可以使用本指南。如果只需要普通批注的文字、作者、回复,以及批注线程是未解决还是已解决的状态,CommentPulse 等现有导出工具可能已经能提供你需要的表格。

Microsoft 将 CommentThreaded.Date 定义为添加批注时的本地时间。原 Stack Overflow 问题的两则答案,一则用最后一条回复的时间代替所需时间,另一则检查普通线程式批注的 XML 并找到 done 标记。最后一条回复可能早于后续的任务完成操作。这两种结果都无法确定后续那个任务事件的时间。

这里的方法对输入有更具体的要求:必须存在实际的文档任务及其已保存的 History。普通批注线程即使已解决,如果没有这些数据,也无法通过本方法恢复任务完成时间。任务时间戳也不能证明用户点击过某个特定界面按钮,更不是整个账户的完整审计轨迹。

2. 保留一份已保存的工作簿副本

将你有权读取的工作簿保存或下载为一份最新的 XLSX 副本。等待保存完成,再运行导出程序。保留原件,并检查副本。输出反映的是该文件中的数据,无法包含之后发生、却从未保存到这份副本中的云端变更。

不要为了准备这项检查而先通过其他电子表格服务转换文件:能使用哪些历史记录,取决于转换后的文件实际保留了什么。较早的导出文件、没有分配的任务的文件,或由省略了任务历史记录的软件生成的文件,都可能正常得出没有可用任务记录的结果。

程序读取采用 ZIP 封装的 XLSX 包,并沿其内部关系引用查找数据。工作表名称与批注部件通过这些关系相连,而不是猜测 sheet1 就对应 threadedComment1。程序不会将工作簿发送到网站,也不会访问你的 Microsoft 账户。

3. 保存完整的本地导出程序

使用 Python 3.12 或更高版本,以及纯文本编辑器。将下方完整程序保存为 export_excel_task_events.py。它仅使用 Python 标准库,因此这个流程不需要 pip 软件包、API 令牌或 Excel 宏。

下面的复制区域是完整程序的单行形式。其中经过转义的换行和缩进,能在你从本页复制时保留 Python 原来的排版。请完全按照所示内容保存为文本;编辑器在显示时自动折行没有关系。不要在这段内容外再加引号。

exec("#!/usr/bin/env python3\n\"\"\"Read saved XLSX document-task history; never infer completion from comments.\n\nUsage: python export_excel_task_events.py workbook.xlsx --out extracted_tasks\nOnly Python 3 standard-library modules are required. The source is never written.\n\"\"\"\nimport argparse, csv, datetime as dt, json, posixpath, re, sys, tempfile, zipfile\nfrom pathlib import Path\nfrom urllib.parse import unquote, urlsplit\nfrom xml.etree import ElementTree as ET\n\nTASK_NS = \"http://schemas.microsoft.com/office/tasks/2019/documenttasks\"\nEVENT_FIELDS = (\"source_part task_id ordinal event_id time_utc_raw event_type \"\n\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\"percent_complete undo_target undone anchor_id sheet cell \"\n\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\"actor_id actor_name actor_provider details_json is_completion_transition\").split()\nTASK_FIELDS = (\"source_part task_id anchor_id sheet cell status progress_percent \"\n\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\"completed_at_utc completed_event_id deleted\").split()\nMAX_XML = 32 * 1024 * 1024\nTIME = re.compile(r\"\\d{4}-\\d{2}-\\d{2}T\\d{2}:\\d{2}:\\d{2}(?:\\.\\d+)?(?:Z|[+-]\\d{2}:\\d{2})?\\Z\")\nOPERATIONS = {\"Create\", \"Assign\", \"Unassign\", \"UnassignAll\", \"SetTitle\",\n\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\"Schedule\", \"Progress\", \"Priority\", \"Delete\", \"Undelete\", \"Undo\"}\n\ndef local(tag):\n\x20\x20\x20\x20return tag.rsplit(\"}\", 1)[-1]\n\ndef required(element, key, context):\n\x20\x20\x20\x20value = element.get(key, \"\")\n\x20\x20\x20\x20if not value.strip():\n\x20\x20\x20\x20\x20\x20\x20\x20raise ValueError(f\"{context}: missing {key}\")\n\x20\x20\x20\x20return value\n\ndef anchor(element):\n\x20\x20\x20\x20child = element.find(f\"{{{TASK_NS}}}Anchor/{{{TASK_NS}}}Comment\")\n\x20\x20\x20\x20return child.get(\"id\", \"\") if child is not None else \"\"\n\ndef utc_time(value):\n\x20\x20\x20\x20if not TIME.fullmatch(value):\n\x20\x20\x20\x20\x20\x20\x20\x20raise ValueError(f\"Invalid task event datetime: {value!r}\")\n\x20\x20\x20\x20parsed = dt.datetime.fromisoformat(value.replace(\"Z\", \"+00:00\"))\n\x20\x20\x20\x20if parsed.utcoffset() not in (None, dt.timedelta(0)):\n\x20\x20\x20\x20\x20\x20\x20\x20raise ValueError(f\"Task event time must be UTC: {value!r}\")\n\x20\x20\x20\x20if value.endswith(\"Z\"):\n\x20\x20\x20\x20\x20\x20\x20\x20return value\n\x20\x20\x20\x20return (value[:-6] if re.search(r\"[+-]00:00$\", value) else value) + \"Z\"\n\ndef resolve(owner, target):\n\x20\x20\x20\x20uri = urlsplit(target)\n\x20\x20\x20\x20if uri.scheme or uri.netloc or uri.query:\n\x20\x20\x20\x20\x20\x20\x20\x20raise ValueError(f\"Invalid internal relationship target: {target!r}\")\n\x20\x20\x20\x20path = unquote(uri.path)\n\x20\x20\x20\x20if not path:\n\x20\x20\x20\x20\x20\x20\x20\x20return owner\x20\x20# A fragment-only relationship refers to this part.\n\x20\x20\x20\x20part = posixpath.normpath(path.lstrip(\"/\") if path.startswith(\"/\") else\n\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20posixpath.join(posixpath.dirname(owner), path))\n\x20\x20\x20\x20if part in (\".\", \"..\") or part.startswith(\"../\") or \"\\\\\" in part or \"\\x00\" in part:\n\x20\x20\x20\x20\x20\x20\x20\x20raise ValueError(f\"Relationship escapes the package: {target!r}\")\n\x20\x20\x20\x20return part\n\nclass Package:\n\x20\x20\x20\x20def __init__(self, archive):\n\x20\x20\x20\x20\x20\x20\x20\x20self.archive, self.names, self.graph, self.kinds = archive, set(), {}, {}\n\x20\x20\x20\x20\x20\x20\x20\x20for entry in archive.infolist():\n\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20if entry.flag_bits \u0026 1:\n\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20raise ValueError(\"Encrypted ZIP entries are not supported\")\n\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20if entry.is_dir():\n\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20continue\n\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20name = entry.filename\n\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20if name in self.names:\n\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20raise ValueError(f\"Duplicate ZIP entry: {name}\")\n\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20if name.startswith((\"/\", \"../\")) or name == \"..\" or posixpath.normpath(name) != name or \"\\\\\" in name:\n\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20raise ValueError(f\"Invalid ZIP part name: {name}\")\n\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20self.names.add(name)\n\x20\x20\x20\x20\x20\x20\x20\x20pending, reached = [\"\"], set()\n\x20\x20\x20\x20\x20\x20\x20\x20while pending:\n\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20owner = pending.pop()\n\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20if owner in reached:\n\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20continue\n\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20reached.add(owner)\n\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20relfile = (posixpath.join(posixpath.dirname(owner), \"_rels\",\n\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20posixpath.basename(owner) + \".rels\")\n\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20if owner else \"_rels/.rels\")\n\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20relations = {}\n\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20if relfile in self.names:\n\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20for rel in self.xml(relfile):\n\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20if local(rel.tag) != \"Relationship\":\n\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20continue\n\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20rid = required(rel, \"Id\", relfile)\n\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20if rid in relations:\n\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20raise ValueError(f\"Duplicate relationship ID in {relfile}: {rid}\")\n\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20kind = required(rel, \"Type\", relfile).rsplit(\"/\", 1)[-1].lower()\n\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20target = required(rel, \"Target\", relfile)\n\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20if rel.get(\"TargetMode\") == \"External\":\n\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20relations[rid] = (kind, None)\n\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20continue\n\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20target = resolve(owner, target)\n\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20if target and target not in self.names:\n\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20raise ValueError(f\"Missing relationship target: {target}\")\n\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20relations[rid] = (kind, target)\n\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20self.kinds.setdefault(target, set()).add(kind)\n\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20pending.append(target)\n\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20self.graph[owner] = relations\n\x20\x20\x20\x20\x20\x20\x20\x20self.reached = reached\n\n\x20\x20\x20\x20def xml(self, name):\n\x20\x20\x20\x20\x20\x20\x20\x20if self.archive.getinfo(name).file_size > MAX_XML:\n\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20raise ValueError(f\"XML part exceeds 32 MiB: {name}\")\n\x20\x20\x20\x20\x20\x20\x20\x20data = self.archive.read(name)\n\x20\x20\x20\x20\x20\x20\x20\x20if b\"\u003c!DOCTYPE\" in data or b\"\u003c!ENTITY\" in data:\n\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20raise ValueError(f\"DTD/entity declarations are not supported: {name}\")\n\x20\x20\x20\x20\x20\x20\x20\x20try:\n\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20return ET.fromstring(data)\n\x20\x20\x20\x20\x20\x20\x20\x20except ET.ParseError as error:\n\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20raise ValueError(f\"Invalid XML in {name}: {error}\") from error\n\n\x20\x20\x20\x20def comment_locations(self):\n\x20\x20\x20\x20\x20\x20\x20\x20books = [p for kind, p in self.graph[\"\"].values() if kind == \"officedocument\" and p]\n\x20\x20\x20\x20\x20\x20\x20\x20if len(books) != 1:\n\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20raise ValueError(\"Expected one package-root officeDocument relationship\")\n\x20\x20\x20\x20\x20\x20\x20\x20book, comments = books[0], {}\n\x20\x20\x20\x20\x20\x20\x20\x20root = self.xml(book)\n\x20\x20\x20\x20\x20\x20\x20\x20if local(root.tag) != \"workbook\":\n\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20raise ValueError(\"The package is not an XLSX workbook\")\n\x20\x20\x20\x20\x20\x20\x20\x20for sheet in root.iter():\n\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20if local(sheet.tag) != \"sheet\":\n\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20continue\n\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20rid = next((v for k, v in sheet.attrib.items() if k.endswith(\"}id\")), \"\")\n\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20kind, part = self.graph[book].get(rid, (\"\", None))\n\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20if kind != \"worksheet\" or not part:\n\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20continue\n\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20for relkind, target in self.graph[part].values():\n\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20if target and relkind in (\"threadedcomment\", \"threadedcomments\"):\n\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20for comment in self.xml(target):\n\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20if local(comment.tag) != \"threadedComment\":\n\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20continue\n\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20cid = required(comment, \"id\", target)\n\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20if cid in comments:\n\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20raise ValueError(f\"Duplicate threaded-comment ID: {cid}\")\n\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20comments[cid] = (sheet.get(\"name\", \"\"), comment.get(\"ref\", \"\"),\n\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20comment.get(\"parentId\", \"\"))\n\x20\x20\x20\x20\x20\x20\x20\x20def location(cid, seen):\n\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20if cid in seen:\n\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20raise ValueError(f\"Cyclic comment parent IDs: {cid}\")\n\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20sheet, cell, parent = comments[cid]\n\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20if not cell and parent in comments:\n\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20return location(parent, seen | {cid})\n\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20return sheet, cell\n\x20\x20\x20\x20\x20\x20\x20\x20return {cid: location(cid, set()) for cid in comments}\n\n\x20\x20\x20\x20def task_parts(self):\n\x20\x20\x20\x20\x20\x20\x20\x20parts = {p for p in self.reached if \"documenttasks\" in self.kinds.get(p, set())}\n\x20\x20\x20\x20\x20\x20\x20\x20if \"[Content_Types].xml\" in self.names:\n\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20for item in self.xml(\"[Content_Types].xml\"):\n\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20if local(item.tag) == \"Override\" and \"documenttasks\" in item.get(\"ContentType\", \"\").lower():\n\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20part = resolve(\"\", item.get(\"PartName\", \"\"))\n\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20if part in self.reached:\n\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20parts.add(part)\n\x20\x20\x20\x20\x20\x20\x20\x20return sorted(parts)\n\ndef parse_task(task, source, locations):\n\x20\x20\x20\x20tid = required(task, \"id\", source)\n\x20\x20\x20\x20history = task.find(f\"{{{TASK_NS}}}History\")\n\x20\x20\x20\x20nodes = [] if history is None else list(history.findall(f\"{{{TASK_NS}}}Event\"))\n\x20\x20\x20\x20aid = anchor(task)\n\x20\x20\x20\x20candidates = {anchor(e) for e in nodes if anchor(e)}\n\x20\x20\x20\x20if not aid and len(candidates) == 1:\n\x20\x20\x20\x20\x20\x20\x20\x20aid = next(iter(candidates))\n\x20\x20\x20\x20status = (\"ok\" if aid in locations else \"unmatched_anchor\" if aid else\n\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\"ambiguous_anchor\" if candidates else \"missing_anchor\")\n\x20\x20\x20\x20sheet, cell = locations.get(aid, (\"\", \"\"))\n\x20\x20\x20\x20state = dict(zip(TASK_FIELDS, [source, tid, aid, sheet, cell, status, \"\", \"\", \"\", False]))\n\x20\x20\x20\x20if not nodes:\n\x20\x20\x20\x20\x20\x20\x20\x20state[\"status\"] = \"missing_history\"\n\x20\x20\x20\x20\x20\x20\x20\x20return [], state\n\x20\x20\x20\x20events, positions, normalized = [], {}, []\n\x20\x20\x20\x20for ordinal, node in enumerate(nodes, 1):\n\x20\x20\x20\x20\x20\x20\x20\x20eid = required(node, \"id\", f\"Task {tid} event {ordinal}\")\n\x20\x20\x20\x20\x20\x20\x20\x20if eid in positions:\n\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20raise ValueError(f\"Duplicate event ID in task {tid}: {eid}\")\n\x20\x20\x20\x20\x20\x20\x20\x20raw = required(node, \"time\", f\"Event {eid}\")\n\x20\x20\x20\x20\x20\x20\x20\x20normalized.append(utc_time(raw))\n\x20\x20\x20\x20\x20\x20\x20\x20actors = node.findall(f\"{{{TASK_NS}}}Attribution\")\n\x20\x20\x20\x20\x20\x20\x20\x20operations = [c for c in node if c.tag.startswith(\"{\" + TASK_NS + \"}\")\n\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20and local(c.tag) in OPERATIONS]\n\x20\x20\x20\x20\x20\x20\x20\x20if len(actors) != 1 or len(operations) > 1:\n\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20raise ValueError(f\"Event {eid}: expected one Attribution and at most one operation\")\n\x20\x20\x20\x20\x20\x20\x20\x20actor = actors[0]\n\x20\x20\x20\x20\x20\x20\x20\x20actor_values = [required(actor, k, f\"Event {eid} Attribution\")\n\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20for k in (\"userId\", \"userName\", \"userProvider\")]\n\x20\x20\x20\x20\x20\x20\x20\x20op = operations[0] if operations else None\n\x20\x20\x20\x20\x20\x20\x20\x20kind, percent, undo = local(op.tag) if op is not None else \"Extension\", \"\", \"\"\n\x20\x20\x20\x20\x20\x20\x20\x20if kind == \"Progress\":\n\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20text = required(op, \"percentComplete\", f\"Event {eid}\")\n\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20if not re.fullmatch(r\"\\+?\\d+\", text) or not 0 \u003c= int(text) \u003c= 100:\n\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20raise ValueError(f\"Event {eid}: percentComplete must be an integer from 0 to 100\")\n\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20percent = int(text)\n\x20\x20\x20\x20\x20\x20\x20\x20if kind == \"Undo\":\n\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20undo = required(op, \"id\", f\"Event {eid} Undo\")\n\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20if undo not in positions or events[positions[undo]][\"event_type\"] == \"Create\":\n\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20raise ValueError(f\"Event {eid}: Undo must target an earlier non-Create event\")\n\x20\x20\x20\x20\x20\x20\x20\x20positions[eid] = ordinal - 1\n\x20\x20\x20\x20\x20\x20\x20\x20event_aid = anchor(node) or aid\n\x20\x20\x20\x20\x20\x20\x20\x20event_sheet, event_cell = locations.get(event_aid, (\"\", \"\"))\n\x20\x20\x20\x20\x20\x20\x20\x20detail = json.dumps({\"attributes\": node.attrib, \"xml\": ET.tostring(node, encoding=\"unicode\")}, ensure_ascii=False)\n\x20\x20\x20\x20\x20\x20\x20\x20values = [source, tid, ordinal, eid, raw, kind, percent, undo, False,\n\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20event_aid, event_sheet, event_cell] + actor_values + [detail, False]\n\x20\x20\x20\x20\x20\x20\x20\x20events.append(dict(zip(EVENT_FIELDS, values)))\n\x20\x20\x20\x20if events[0][\"event_type\"] != \"Create\" or sum(e[\"event_type\"] == \"Create\" for e in events) != 1:\n\x20\x20\x20\x20\x20\x20\x20\x20raise ValueError(f\"Task {tid}: history must start with its only Create event\")\n\x20\x20\x20\x20for event in reversed(events):\n\x20\x20\x20\x20\x20\x20\x20\x20if event[\"event_type\"] == \"Undo\" and not event[\"undone\"]:\n\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20events[positions[event[\"undo_target\"]]][\"undone\"] = True\n\x20\x20\x20\x20progress = 0\n\x20\x20\x20\x20for event, time in zip(events, normalized):\n\x20\x20\x20\x20\x20\x20\x20\x20if event[\"undone\"]:\n\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20continue\n\x20\x20\x20\x20\x20\x20\x20\x20kind = event[\"event_type\"]\n\x20\x20\x20\x20\x20\x20\x20\x20if kind == \"Progress\":\n\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20new = event[\"percent_complete\"]\n\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20if progress \u003c 100 and new == 100:\n\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20state[\"completed_at_utc\"], state[\"completed_event_id\"] = time, event[\"event_id\"]\n\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20event[\"is_completion_transition\"] = True\n\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20if new \u003c 100:\n\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20state[\"completed_at_utc\"], state[\"completed_event_id\"] = \"\", \"\"\n\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20progress = new\n\x20\x20\x20\x20\x20\x20\x20\x20elif kind in (\"Delete\", \"Undelete\"):\n\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20state[\"deleted\"] = kind == \"Delete\"\n\x20\x20\x20\x20state[\"progress_percent\"] = progress\n\x20\x20\x20\x20return events, state\n\ndef extract(path):\n\x20\x20\x20\x20events, tasks, task_ids = [], [], set()\n\x20\x20\x20\x20try:\n\x20\x20\x20\x20\x20\x20\x20\x20with zipfile.ZipFile(path, \"r\") as archive:\n\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20package = Package(archive)\n\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20locations = package.comment_locations()\n\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20for source in package.task_parts():\n\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20root = package.xml(source)\n\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20if root.tag != f\"{{{TASK_NS}}}Tasks\":\n\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20raise ValueError(f\"Unexpected Tasks root/namespace in {source}\")\n\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20for task in root.findall(f\"{{{TASK_NS}}}Task\"):\n\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20rows, state = parse_task(task, source, locations)\n\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20if state[\"task_id\"] in task_ids:\n\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20raise ValueError(f\"Duplicate task ID: {state['task_id']}\")\n\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20task_ids.add(state[\"task_id\"])\n\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20events.extend(rows)\n\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20tasks.append(state)\n\x20\x20\x20\x20except (zipfile.BadZipFile, RuntimeError, NotImplementedError, OSError, KeyError) as error:\n\x20\x20\x20\x20\x20\x20\x20\x20raise ValueError(f\"Cannot read XLSX package: {error}\") from error\n\x20\x20\x20\x20return events, tasks\n\ndef csv_safe(value):\n\x20\x20\x20\x20if isinstance(value, str) and (re.match(r\"\\s*[=+@-]\", value) or value.startswith((\"\\t\", \"\\r\", \"\\n\"))):\n\x20\x20\x20\x20\x20\x20\x20\x20return \"'\" + value\n\x20\x20\x20\x20return value\n\ndef export(path, outdir):\n\x20\x20\x20\x20events, tasks = extract(path)\n\x20\x20\x20\x20destination = Path(outdir)\n\x20\x20\x20\x20names = (\"events.csv\", \"tasks.csv\", \"data.json\", \"summary.txt\")\n\x20\x20\x20\x20if destination.exists():\n\x20\x20\x20\x20\x20\x20\x20\x20raise ValueError(f\"Output directory already exists: {destination}; choose a new --out directory\")\n\x20\x20\x20\x20destination.mkdir(parents=True)\n\x20\x20\x20\x20summary = (f\"Tasks: {len(tasks)}\\nEvents: {len(events)}\\n\"\n\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\"Source workbook opened read-only. Only package-root-reachable task parts included.\\n\"\n\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\"No completion time inferred from done flags, replies or last-edit timestamps.\\n\"\n\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\"completed_at_utc is the current effective task progress transition to 100%; deletion is separate.\\n\"\n\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\"undone reflects the final saved history, not every past UI state.\\n\"\n\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\"is_completion_transition marks each effective progress change from below 100 to 100.\\n\"\n\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\"Missing history/anchors are explicit; unmatched tasks can still have task event times.\\n\"\n\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\"CSV formula-like text is prefixed with an apostrophe; data.json preserves original field values.\\n\"\n\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\"Raw event datetime is preserved; timezone-free task times are interpreted as UTC per MS-OTASKXML.\\n\"\n\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\"No task rows means no reachable stored task records, not that no comments were resolved.\\n\"\n\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\"Limits: XML parts \u003c=32 MiB; encrypted files and malformed/ambiguous histories fail.\\n\")\n\x20\x20\x20\x20with tempfile.TemporaryDirectory(dir=destination) as temporary:\n\x20\x20\x20\x20\x20\x20\x20\x20temporary = Path(temporary)\n\x20\x20\x20\x20\x20\x20\x20\x20for name, fields, rows in ((\"events.csv\", EVENT_FIELDS, events), (\"tasks.csv\", TASK_FIELDS, tasks)):\n\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20with (temporary / name).open(\"w\", newline=\"\", encoding=\"utf-8-sig\") as stream:\n\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20writer = csv.DictWriter(stream, fieldnames=fields)\n\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20writer.writeheader()\n\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20writer.writerows({k: csv_safe(v) for k, v in row.items()} for row in rows)\n\x20\x20\x20\x20\x20\x20\x20\x20(temporary / \"data.json\").write_text(json.dumps({\"events\": events, \"tasks\": tasks}, ensure_ascii=False, indent=2), encoding=\"utf-8\")\n\x20\x20\x20\x20\x20\x20\x20\x20(temporary / \"summary.txt\").write_text(summary, encoding=\"utf-8\")\n\x20\x20\x20\x20\x20\x20\x20\x20for name in names:\n\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20\x20(temporary / name).replace(destination / name)\n\x20\x20\x20\x20return events, tasks\n\ndef main(argv=None):\n\x20\x20\x20\x20parser = argparse.ArgumentParser(description=__doc__)\n\x20\x20\x20\x20parser.add_argument(\"workbook\", help=\"Saved .xlsx workbook (read-only)\")\n\x20\x20\x20\x20parser.add_argument(\"--out\", required=True, help=\"New directory for the four output files\")\n\x20\x20\x20\x20args = parser.parse_args(argv)\n\x20\x20\x20\x20try:\n\x20\x20\x20\x20\x20\x20\x20\x20events, tasks = export(args.workbook, args.out)\n\x20\x20\x20\x20except (ValueError, OSError) as error:\n\x20\x20\x20\x20\x20\x20\x20\x20parser.exit(2, f\"Error: {error}\\n\")\n\x20\x20\x20\x20print(f\"Exported {len(events)} events and {len(tasks)} tasks to {args.out}\")\n\x20\x20\x20\x20return 0\n\nif __name__ == \"__main__\":\n\x20\x20\x20\x20sys.exit(main())\n")

输入文件应是你已经获准读取的工作簿。脚本只读取该文件,并写出自己的报告。请将这些报告与原始的已保存副本放在一起,以便利用源部件、任务和事件标识符核对结果。

4. 将运行结果写入新输出文件夹

将程序放在已保存工作簿的旁边,或使用完整路径。在该文件夹中打开终端。如果系统中 Python 3 的命令是 python3,请运行下列命令;在 Windows 上,如果你使用的 Python 启动器是 py -3,就用它替换 python3。

python3 export_excel_task_events.py "review-copy.xlsx" --out "task-report"

为工作簿的每个已保存版本使用一个新的输出文件夹名称。等待程序显示成功摘要后,再将报告视为完整结果。如果程序报告数据无效或不受支持,请根据该错误处理,不要把部分结果或空结果当成已完成的导出。

新文件夹内含 events.csv、tasks.csv、data.json 和 summary.txt。两个 CSV 文件分别是事件表和任务表;summary.txt 提供数量统计及解读限制。data.json 为程序处理保留了原始字段字符串。接下来的章节说明哪些日期有意义,以及如何区分缺少日期和任务未完成。

5. 复制日期前,先查看任务结果

先打开 tasks.csv。每行标明其 source_part 和 task_id;如果能够建立与批注的关联,还会显示 anchor_id、sheet 和 cell。先检查 status:ok 表示已找到关联。在将某个时间戳对应到特定工作表批注之前,应先留意 missing_history、missing_anchor、unmatched_anchor 或 ambiguous_anchor。

对于成功建立关联的任务,progress_percent 描述的是按顺序应用有效历史记录后得到的状态。completed_at_utc 和 completed_event_id 标明使任务进入当前完成状态的那个有效 Progress 事件。如果后续有效的进度值低于 100,当前完成时间字段就会被清空。在未变为未完成的情况下重复出现 100,并不会形成新的完成状态转换。

deleted 是独立的标记。任务可以在被标记为已删除的同时保留完成历史记录。不要悄然丢弃该标记,也不要把已删除的任务呈现为仍有效的分配任务。同样,当前完成时间字段为空,也不表示该任务以前从未完成过。

在后续报告中,请将原始的源部件、任务和事件标识符与日期一并保留。这些标识符能让你将结果追溯到已保存的文件包,也能避免将不同任务历史记录中重复使用的事件 ID 当成同一事件。

6. 按 XML 顺序检查有效事件

events.csv 保留 ordinal、原始的 time_utc_raw 字符串和 event_id,同时包含 event_type、操作者信息以及任务/批注引用。is_completion_transition=True 表示一次有效的 Progress 从低于 100 变为 100 的变化。undone=True 标记从最终有效历史记录中排除的记录;这些行仍会保留,便于核对。这些布尔值在 CSV 中写为 True/False,在 JSON 中写为 true/false。

应按 XML 序列评估,而不是按时间戳排序。Microsoft 规定,后续仍有效的 Undo 可以排除先前的事件,而 Undo 本身也可以被撤销。完成这些排除后,再按保存的顺序依次应用其余事件。取最大日期或最后回复时间,都无法替代这个过程。

考虑这样一个合成序列:Create;Progress 100;Progress 0;Progress 100;用 Undo 撤销第二次完成;再用 Undo 撤销上一个 Undo。最终有效的历史记录会重新包含第二次完成。保留下来的完成事件时间取自该 Progress 事件。较晚发生的“撤销 Undo”的时间,不会被重新标记成一次新的 Progress 完成时间。

这份报告描述的是已保存文件中最终仍有效的历史记录。它不会重建界面过去每次可能显示任务已完成的时刻,也不会把每一次进度降低都称为点击了 Reopen。这些是不同的判断。

7. 理解无法提取与数据无效的情况

未找到可访问的任务历史记录:文件可能包含普通批注而没有分配的任务,也可能保存的是较早的状态,或在导出时省略了任务数据。如能取得原始工作簿的最新 XLSX 副本,请检查它。导出程序无法从 done 标记恢复文件中缺失的事件。

missing_history:存在任务,但缺少可用的事件序列,或该序列为空。missing_anchor:未找到可用的批注引用。unmatched_anchor:存在引用,但未能沿工作簿的关系引用找到对应的线程式批注。ambiguous_anchor:缺少任务级引用,且各事件的引用互不一致。尚未关联到批注的任务仍可能有事件时间;仅凭这些时间,无法确定它们属于哪个工作表批注。

如果缺少任务级 anchor,而所有可用的事件级 anchor 都指向同一处,本程序会使用这个唯一引用建立关联。否则,会保留缺失或有歧义的结果。不要根据批注文字或文件名中的数字猜测所属工作表。

事件数据无效属于另一类错误。同一任务历史记录中存在重复 ID、Undo 没有指向此前允许被撤销的事件、时间戳格式错误,或进度值超出范围时,都不能据此猜出一个日期。保留文件副本及报告的错误。如果可以,另行获取有效的已保存文件;仅为通过检查而手动修改历史记录,会改变证据本身。

如果历史记录不可用,而后续工作又需要可靠的完成日志,请用一个专门字段或由你掌控的其他工作流程记录今后的完成时间。这样做是在创建新记录,无法重建过去缺失的时间。

8. 按文本导入并核对导出结果

导入 CSV 文件时,在电子表格的导入设置中将标识符列和时间戳列按文本处理。这样可以保持保存的字符串原样可见,避免自动转成日期或数值。带引号的 CSV 字段可能包含逗号或换行,因此应统计解析后的记录数,而不要按文本文件的行数计数。

CSV 报告会在类似公式的文本前加上一个单引号,包括忽略前导空白后以 =、+、- 或 @ 开头的文本。data.json 保留未加此前缀的原始字段值。如需精确的原始文本,请使用这些 JSON 值;不要先去掉前缀,再让不可信文本作为公式打开。details_json 中的事件 XML 会经过解析再重新序列化,因此其中的命名空间前缀和 XML 格式并非按原始字节复制。

核对汇总报告中的任务数/事件数与解析后的表格是否一致。至少选择一个已知任务,核对其工作表/单元格和事件标识符;然后在使用日期前,逐一检查所有缺失或未匹配的状态。筛选完成状态转换时,要同时依据转换标记、记录是否有效及其 undone 状态。

一并保留原始的已保存工作簿、所有报告文件和当时所用的确切程序版本。如果工作簿后来发生变化,就把新的导出结果写入新文件夹,再比较两份快照。不要覆盖旧报告后,还把新报告描述为来自旧文件的记录。

9. 已验证的范围

在 Python 3.12.14 上,常规形式的程序通过了 26 项合成 ZIP/工作簿测试。一位独立审阅者运行了 8 项单独编写的测试,其中包括对 64 组生成的历史记录与递归 Undo 方法进行对照。上面的单行可复制形式被解码还原为与常规源代码完全一致的代码,并再次通过同一套 26 项测试(包括 CLI 检查);这些测试样本使用了官方的文档任务关系 URI。这些均为合成文件测试,并非 Excel GUI、Windows/macOS 或真实用户工作簿测试。

检查涵盖了基于关系引用的工作表/批注对应关系、事件 ID 的作用范围、历史记录缺失和 anchor 关联的各类结果、撤销 Undo、重复完成、后续进度回到未完成、删除、CSV/JSON 文本处理、输入文件字节保持不变,以及拒绝覆盖已存在的输出文件夹。本脚本将每个所读 XML 部件的大小限制为 32 MiB,把解析数据保存在内存中,不支持加密的工作簿包。未对大型生产环境工作簿进行容量测试。

Microsoft 的任务格式文档为保存的 ID、时间、进度和 Undo 语义提供了依据。CommentPulse 自己的文档另外说明了其现有导出工具,以及该工具在任务数据方面的限制。本程序和相关检查将这些资料组合成有适用前提的本地提取流程;它们并不能证明每一种 Excel 安装都会写入相同的历史记录,也不能证明原提问者缺失的事件就存在于文件中。

6 个按 XML 顺序排列的合成事件依次为 Create、Progress 100、Progress 0、Progress 100、撤销事件 4 的 Undo,以及撤销事件 5 的 Undo。事件 5 被撤销,事件 4 因而恢复有效。当前进度为 100%,保留的完成事件时间是事件 4 的 09:30 UTC。
使用合成的已保存历史数据绘制的原创示意图。撤销 Undo 后,事件 4 重新生效。Progress 事件 2、3、4 均保持有效;当前进度为 100%,事件 4 提供最近一次有效的完成时间,即 09:30 UTC。09:50 UTC 的事件 6 是 Undo,因此完成事件时间仍为 09:30 UTC。 Watch at Ease
